Planetary Ball Mill Super Fine Grinding Laboratory Planetary Ball Mill for Battery Materials and Nano Powder Processing

Name: Planetary Ball Mill Super Fine Grinding Laboratory Planetary Ball Mill for Battery Materials and Nano Powder Processing
Brand: LONROY
Price: 1 USD

Cheap Planetary Ball Mill Super Fine Grinding Laboratory Planetary Ball Mill for Battery Materials and Nano Powder Processing for sale

Brand Name : LONROY

Place of Origin : Guangdong, China

MOQ : 1

Voltage : 220 V

Protection Class : Ip56

Feeding particle size : soft ≤10mm, other material ≤3mm

Ball mill jar volume : 0.05L-5L/pc, totally 0.2L-100L

Rotating speed : 0-870rpm (normal), 0-1400rpm (high-speed)

Discharge particle size : Min. As 0.1um

Speed ratio : 1:2 (20-200L productive planetary ball mill can be 1:1.5)

Speed regulation : stepless speed regulation, 0.2rpm

Program control : Microcomputer chip control with forward/inversion programs

Max working time : 72 hours (timer 0-9999h)

Motor power : 0.55kw, 0.75kw, 1.5kw, 2.2kw, 3KW, 4KW (model dependent)

Motor material : Pure copper

Ball mill environments : Vacuum, inert gas, low temperature, high temperature

Speed ratio range : 1:2 (standard), 1:1.5 (productive models)

Program duration : 0-999 min

Contact Now

Planetary Ball Mill Super Fine Grinding Laboratory Planetary Ball Mill for Battery Materials and Nano Powder Processing

Product Description

Introduction

Planetary ball mill is a necessary device of high-tech materials mixing, fine grinding, sample making, new product development and small batch production. Lonroy planetary ball mill owns small volume, high efficiency, low noise and functional features which is a ideal equipment for R&D institution, university, enterprises laboratory to get samples ( you can get four samples from each batch at the same time). You can also grind powder samples under the vacuum state when equipped with vacuum ball mill jars.

Planetary Ball Mill Super Fine Grinding Laboratory Planetary Ball Mill for Battery Materials and Nano Powder Processing

Technical Specification

Ball mill jar volume	0.05L-5L/pc, totally 0.2L-100L
Feeding particle size	soft ≤10mm, other material ≤3mm
Discharge particle size	Min. As 0.1um
Speed ratio (revolution: rotation)	1:2 (20-200L productive planetary ball mill can be 1:1.5)
Rotating speed	0-870rpm( normal), 0-1400rpm (high-speed)
Speed regulation	stepless speed regulation, 0.2rpm
Program control	Our ball mill adopts high-tech microcomputer chip control,it can runs by set up the forward and inversion alternately repeatedly program(0-999 min) and forward, pause, inversion, pause, forward (0-999 min) alternating operation program, especially suitable for cooling or intermittent operation.
Max. Continuous working time (full load)	72 hours( timer 0-9999h)
Motor power	main power is 0.55kw, 0.75kw, 1.5kw, 2.2kw, 3KW, 4KW as per the model and ball mill loading weight. The motor is made by pure cupper.
Ball mill environments	Vacuum, inert gas, low temperature, high temperature
